IEC0587 ASTMD2303 Standards Testing High Voltage Tracking Machine

Name: IEC0587 ASTMD2303 Standards Testing High Voltage Tracking Machine
Brand: Daxian
Price: 1 USD

China IEC0587 ASTMD2303 Standards Testing High Voltage Tracking Machine wholesale

Brand Name : Daxian

Model Number : DX8427

Certification : IEC60587-2007, ASTM D2303

Place of Origin : China

MOQ : one set

Price : Negotiation

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash

Supply Ability : 15 sets per month

Delivery Time : 15work days

Packaging Details : Wooden Case

Name : High Voltage Tracking Index Flammability Tester

Standard : IEC60587-2007, ASTM D2303

Product type : plastic Testing Equipment

Power : 220V/50HZ

Warranty : 1 Year

Power supply : AC 220V 50Hz

Drop size : 44 to 50 drops / cm3

Electrode Pressure : 1.00N±0.05N

Contact Now

IEC60587 8KV Automatic High Voltage Tracking Index Tester

IEC0587 ASTMD2303 Standards Testing High Voltage Tracking Machine

IEC0587 ASTMD2303 Standards Testing High Voltage Tracking Machine
Technical Description:

This product is used in electrical products under the influence of moisture and impurity environment, between the different polarity of the live parts or between the live parts and the grounding metal parts may cause insulation on the leakage, the resulting arc caused by electrical breakdown of the electrical or due to Discharge causes the material to erode and even ignite the fire. The test apparatus is a destructive test of the insulating material in the above case to test and evaluate the relative resistance to traceability of the insulator in the presence of electric and impurity water at a specified voltage. Applicable to electrical and electronic products, household appliances, solid electrical insulation materials and their products, such as: relay socket, switch cover, contactor body.

Standard:
IEC60587-2007, ASTM D2303

Parameters:

Box	≥ 0.5 cubic meters
Drop size	44 to 50 drops / cm3
Power supply	AC 220V, 50Hz
Electrical load	0 ~ 6000V adjustable
Drip height	30mm ~ 40mm adjustable
Electrode Pressure	1.00N±0.05N
Flow range	0.00185 to 2 ml / min
Speed	0.1 to 15 rev / min

Tracking resistance tester
Erosion resistance tester
Comparative Tracking Index (CTI) tester
Electrical tracking test machine
Insulation tracking tester
High-voltage tracking test equipment
Dielectric tracking tester
Contamination tracking test apparatus
Electrical erosion test machine
Tracking and erosion test apparatus
IEC 60587 test equipment
Insulation material tracking tester
High-voltage erosion tester
Electrical breakdown tester
Tracking resistance evaluation equipment
