UL1581 Vertical Horizontal Wire Testing Equipment Combustion Resistance Test

Brand Name : DAXIAN

Model Number : DX8508

Certification : UL1581.UL13.UL444.UL1655-VW-1

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash

Supply Ability : 30 sets per month

Delivery Time : 30 days after order confirmed

Packaging Details : Standard export wooden case

Standards : UL1581.UL13.UL444

Power supply : 220 VAC, 50 Hz

Weight : 40kg

Fuel : gas and methane

Warranty : 12 months

Delivery time : 10 days

Contact Now

Wire and cable vertical horizontal combustion testing machine UL444

Product introduction:


It is suitable for the combustion resistance test of various organic materials, such as wire and cable insulation, printed circuit board material, IC insulator, etc. when the specimen is on the top of the flame, it will be burned for 15 seconds and extinguished for 15 seconds. After 5 times of repetition, the burning condition of the sample can be checked. The burning, extinguishing time and repetition times can be set, and the operation can be automatic.

Standard:

UL1581.UL13.UL444.UL1655-VW-1.

Technical Parameters:

Vertical combustion chamber internal dimension 305 * 355 * 610mm
Horizontal combustion chamber internal dimension 305 * 355 * 610mm
Fuel gas and methane (provided by customers)
Power supply 220 VAC, 50 Hz
Weight 40kg


Vertical spark nozzle:

- nozzle angle is 20 degrees, with gas control valve.


Horizontal spark nozzle:

- nozzle angle is 90 degrees, with gas control valve.
-Vertical or horizontal nozzle selection mode.
- Select Manual / automatic mode.
- When the preset data is reached, the machine will automatically stop the test.

UL1581 Vertical Horizontal Wire Testing Equipment Combustion Resistance Test

UL1581 Vertical Horizontal Wire Testing Equipment Combustion Resistance Test
